    BluStream 4×4 Advanced Video Wall Processor

    ★★★★★ 4.9 · 38 reviews · In stock · UK delivery

    MX44AVW

    £1,699.00 + VAT

    Public sector & education POs accepted
    UK delivery
    Bulk pricing available
    Lifetime phone support
    Free technical support
    Questions? We're here to help
    Phone: 0151 372 7766
    Email: info@futurevisuals.co.uk
    Request Bulk Quote

    About this item

    The MX44AVW is an advanced 4K HDMI 2.0 high-speed video processing system suitable for multiple applications. It can be configured in three output modes; 4×4 seamless matrix switcher,  Advanced video wall solution and the Quad multi-view presentation system.

    The MX44AVW supports sophisticated video wall arrangements, allowing individual panel rotation and overlap. It also enables multiview layouts with pre-defined or custom options, including picture in picture, picture outside picture, picture by picture, and up to four window configurations.

    Control and configuration of the MX44AVW is available through a web browser interface, with additional options using the front panel buttons, IR remote control, RS232 interface, or TCP/IP. The MX44AVW is designed to create visually striking video wall installations in retail and showcase environments.

    Product Code

    MX44AVW

      Request Bulk Quote

      This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply. We will never sell or share your information.
      Close Form Window

      BluStream 4×4 Advanced Video Wall Processor

      Advanced 4×4 4K HDMI 2.0 Multi-Purpose Video Processor with Matrix, Multi-View and Video Wall with Overlap and Rotation of Displays, Seamless Switching, Audio Embedding & Breakout, IR Routing, RS-232, IR, and TCP/IP Control and Web-GUI

      Key Features:

      • Advanced 4K HDMI 2.0 multi-purpose high-speed video processor supporting matrix, multiview, and video wall function
      • Advanced video wall configuration allowing individual overlap and rotation of panels
      • Multiview mode supports PIP, PBP, POP, Dual, Triple and Quad-windows layouts with pre-defined and customisable configurations
      • Seamless video switching
      • Supports HDMI 2.0 4K UHD 60Hz 4:4:4 18Gbps specification including HDR
      • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
      • Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
      • HDMI audio breakout to analogue L/R audio and optical digital outputs concurrently
      • IR routing
      • Control via front panel, IR, RS-232, TCP/IP and web-GUI
      • Supplied with Blustream 5V IR receiver and remote control
      • HDCP2.2 compliant with advanced EDID management



      Please note – a 1080i image is only supported in Matrix and Multiview mode, but will not work on Video Wall mode.

      Box Contents:

      1 x MX44AVW
      1 x Remote control
      1 x IR Control Cable – 3.5mm-3.5mm Cable
      1 x 19″ Rack Mounting kit
      4 x Mounting feet
      1 x Quick Reference Card
      1 x IEC Power Cable

      mx44avw scaled
