IP350UHD-RX
£749.00 + VAT
The Blustream IP300UHD series video over IP distribution platform enables virtually latency free one frame distribution of 4K 18Gbps HDMI video over a 1Gb managed network. Fully interoperable with the IP300UHD product line, the IP350UHD-RX is a Dante enabled 4K HDMI receiver that uses visually lossless compression to deliver 18Gbps HDMI, ARC eARC and optical audio return, embedded audio, Dante and AES67 audio, along with bi directional IR, RS 232 and USB KVM over distances of up to 100 metres on standard copper networks or over longer distances via the integrated fibre SFP interface. The IP350UHD-RX supports both video and Dante audio distribution on a single network, with a second RJ45 port allowing the Dante audio network to be separated from the video over IP network for larger or independently managed systems. Featuring a full 18Gbps HDMI scaling chipset, the HDMI output can be downscaled to support legacy displays within the same system as full 4K distribution, while also enabling video wall creation. Power can be supplied via PoE from a compatible network switch or locally if PoE is not available, and with multiple configuration options the flexibility of this video over IP platform makes it suitable for a wide range of commercial and residential installations.
18Gbps UHD Video Receiver over 1Gb Network, Built-in Video Scaler, Video-wall mode, 2ch Dante Audio Transmitter/Receiver, Dual RJ45 & SFP Network Ports, Bi-directional IR, RS-232 & USB/KVM, PoE, Analogue Audio Breakout and HDCP 2.2
• Advanced 4K HDMI 2.0 video over 1Gb managed network supporting 18Gbps HDMI signals
• Virtually unlimited system size
• Extends HDMI up to a distance of 100m over a single CAT cable
• SFP port for signal distribution over fibre
• Supports up to 4K UHD 60Hz 4:4:4
• Supports HDR
• Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
• Extends HDMI and Dante up to a distance of 100m over a single CAT cable
• Dual RJ45 network ports configurable for independent or combined HDMI and Dante signal distribution
• SFP port for independent or combined HDMI and Dante signal distribution over a single fibre cable
• Advanced signal management for independent routing of IR, RS-232, USB/KVM, audio and video
• PoE (Power over Ethernet) to power Blustream unit from PoE switch
• HDCP 2.2 compliant with full 18Gbps scaling capabilities for inclusion of non-4K / legacy displays whilst distributing 4K to other parts of the system
• Analogue L/R audio output supports both balanced and unbalanced audio signals
• HDMI ARC, eARC or optical audio return from display to an IP300UHD or IP350UHD transmitter
• Optical (S/PDIF) input for 2ch optical audio return that can be fed into Dante network
• OLED front panel display for advanced system information and manual configuration
• Optional 24V power supply (should Ethernet switch not support PoE)
• Compatible with Blustream IP300UHD-TX and IP350UHD-TX/RX products
• Features 4 operational modes:
– Matrix distribution (requires 1Gb network switch)
– Video wall (requires 1Gb network switch)
– One-to-one HDMI extender (no network switch required)
– One-to-many HDMI extender (no network switch required)
1 x IP350UHD-RX
1 x IRR Receiver
1 x IRE1 Emitter
1 x Audio 5-pin Phoenix Connector
1 x Serial 3-pin Phoenix Connector
1 x Mounting Kit
Want to know more about this solution? Contact our friendly and specialist sales team today.
